CTS - Model Series 285S/N -Flange Mount Non-Contacting Position Sensor

Compact 45 mm x 22 mm size, Hall-effect technology, Extended rotational life (10 Million cycles), Wide temperature range (-40°C to +125°C), Precision linearity (± 0.5% and ± 0.25% options), Dust & water protection (IP50, 54 and 67 options), Single and dual output.
