As the world’s leading bore gauge manufacturer, Bowers Group has also earned a reputation for manufacturing custom heads for non-standard applications.
Most popular related searches
Examples of our custom gauging solutions are as follows:
- Slot Width
- Blind Bores
- Gun Barrel Head
- Seat Pockets
- Dovetail Slots & Turbine Blade Grooves
- Soft Drink Can
- Right Angled Adapter
- Irregular Spacing
- Brake Caliper
If you have a gauging problem that needs solving, get in contact and we will rise to the challenge.
SLOT WIDTH
- Small slot widths from 2-6mm
- Large Slot width from 6-100mm
BLIND BORES
- Standard between 2-6mm and 12.5-300mm. Between 6-12.5mm on request.
GUN BARREL HEAD
- For the measurement of smooth bore and rifled bore gun barrels. Major and minor diameters measured deep into bores.
SEAT POCKETS
- Internal measurement of surface/subsea valve cavity-seat pockets for the oil and gas industry
- A one-piece right-angle adaptor to allow entry down a perpendicular bore, allowing measurement to take place at 90 degrees to entry of the bore.
- Optimised anvil form and guide pieces aid entry and position the measuring head correctly for higher accuracy measurements and ease of use for operator.
DOVETAIL SLOTS & TURBINE BLADE GROOVES
- 2 Point head solution based on the popular Bowers XT system.
- The system incorporates custom contacts for high accuracy.
- The Bowers XT digital readout offers the capability to send data for SPC and part traceability.
SOFT DRINK CAN
- Internal measurement of a soft drink can
- 3 Point XT Anvil head based on 35-50mm body size, used with XT Holematic Xtreme pistol grip. High accuracy measurement of groove that’s inaccessible to a typical caliper
- 3 Point XT Anvil head used with XT Holematic Xtreme pistol grip. Measurement of internal diameter with 360 degree wrap-around anvils prevents/limits distortion of the thin walled can
RIGHT ANGLED ADAPTOR
- Right angled adaptor for hard-to-reach bores
IRREGULAR SPACING
- Available between 16-300mm diameter to measure between odd spaced lobes.
BALL SCREWS
- Internal measurement of ball-screws for the defence, aerospace, automotive and machine tool industry.
- Optimised anvil form featuring customised contacts for high accuracy.
- 3 Point head solution based on the popular Bowers XT system.
- Automated systems possible
