DataVOLT - High-Speed Logger
Fulcrum3D has developed DataVOLT, a specialised high-speed logger for all your data management requirements.
Designed for fully remote operations with on-board storage and constant, high-speed data download, very high data volumes can be managed and accessed 24/7 via FlightDECK, the online portal.
FlightDECK facilitates easy, fast data download and allows modifications of the volume of valid data – from your desk or mobile device. This can save a significant amount of time, resources and cost by facilitating easy transfer of data into site analysis, early identification of site challenges related to unexpected data (for example wind shear) and constant monitoring of sensor availability.
DataVOLT is designed for fully remote operations with data automatically uploaded to Fulcrum3D’s servers for client access via the web.
The DataVOLT platform allows connection of a variety of sensors for almost any monitoring application and can be integrated into any remote monitoring requirement. It is suitable for Met Mast or stand-alone monitoring and produces high sampling frequencies – up to several hundred samples per second, with all parameters for statistical aggregation to meet user requirements.
DataVOLT can be integrated into any remote monitoring requirement and is suitable for both Met Mast or stand-alone monitoring in addition to noise and solar monitoring.
The base package includes:
- DataVOLT high speed data logger
- Standard mounting brackets
Detailed investigation of high speed events
- Impact of cloud onset on irradiance measurements or solar power output
- Assessment of scalar – vector averaging of wind vectors
- Eddy flux covariance measurements
With high on-board storage and constant data download, including:
- High sampling rate / high resolution photography
- Sound recordings
- High sampling rate time series from multiple measurement instruments
- Internet time protocol time stamp for all measurement parameters – no time-clock adjustments
- Communication via LTE/3G or satellite for automatic data retrieval automatically and upload to secure servers
A portable, robust unit with in-built security
- Fully portable and operated remotely
- Continuous remote interrogation to ensure correct operation
- Integrated solar power supply providing non-stop power with 7+ days energy storage to cover cloudy periods
- GPS receiver – a locator and security device to protect against theft
- Radiation shielded ip68 enclosure to survive in the harshest environments
Instruments of various designs and classes can be supplied with or without calibration certificates.Digital camera systems (including CloudCAM)Wind speed and direction
- Anemometers
- Wind vanes
High speed wind monitoring
- Using ultrasonics – 2D and 3D
- Comparison of Vector and Scalar averaging
Solar irradiance measurements
- Including high speed rate of change detection
Rain measurements
- Rain accumulation
- Rain rate
Temperature, pressure and humidity
- Functional in a variety of climate conditions
- Radiation shielded ip68 enclosure to survive in the harshest environments
- Robust unit, manufactured in Australia, tested around the world
Sound recording
