ICI-Caldaie - Model DEG -Deaerator
The DEG deaerators are devices at atmospheric pressure designed for the thermophysical degassing of the steam boiler feed water. The degassing process is performed by means of a controlled steam injection inside the storage tank in order to increase the internal water temperature. This appliance is part of the condition provided by the Art. 3 Par. 3 of the PED Directive 2014/68 / EU.
Provided with:
- steam diffuser pipe inside the tank
- sheet steel support saddles able to ensure unit support
- insulating coating with high density mineral wool and aluminium sheet finish
The deaerator is available in the S235JR steel or AISI 304 stainless steel versions.
Data concerning the feed water in the deaerator:
- Inlet water pressure: 1 + 3 bar
- Temperatura dell’acqua in ingresso: 10 + 35 °C
Standard equipment:Thermoregulating unit for temperature maintenance (90°C) in the storage tank including:
- automatic or pneumatic modulating two-way valve
- temperature sensor
- steam filter
- 2 shut-off globe valves
- bypass globe valve
Blowdown unit including:
- bypass globe valve
Make-up feed water unit including:
- water solenoid valve
- water filter
- 2 shut-off ball valves
- bypass ball valve
Automatic conductivity probe level regulator including:
- solenoid valve opening and closing probes
- probe for alarm and low level signalling
Boiler control panel IP55 1/N ~ 230V 50 Hz
