BHS FiberPureDebris Screen System

SHARE

The BHS FiberPure Screen is a series of 12 specialized Debris Roll Screen shafts used to treat the two-dimensional product carried over the Polishing Screen. The Tri-Discs aggressively agitate the material to remove small contaminants such as wet tissue, toweling, diapers, candy wrappers, and other like items. The result is a two-dimensional material stream consisting of mostly high-quality fiber. This material stream is often treated optically to remove plastic film or fiber.

Most popular related searches
  • Removes small and soiled fiber and plastics to ensure commodity quality
  • Tri-Disc in-line configuration provides precise sizing
  • Aggressively agitates material for separation efficiency in relatively small footprint
  • Provides even flow infeed to fiber or plastic optical sorter
  • Application: Removes small contaminants from the fiber stream after a Polishing Screen in MSW applications
  • Screen width: 108", 120" (2740 mm, 3050 mm)
  • Inter-Face Openings: 3 1/4", 4 1/4" 5 1/4", 6 1/4", 7 1/4" x 5" (83mm, 108mm, 133mm, 159mm, 184mm x 127mm)
  • Motors: SEW-EURODRIVE high efficiency gear motors
  • Reducers: Shaft mounted
  • Drive Guards: Drive system is enclosed in a solid guard with lift off door for easy removal and replacement. Grease
  • fittings are plumbed to a common point outside guard for convenient bearing maintenance.
  • Bearings: Dodge SC Tapped Base
  • Sprockets: 80Q17 hardened double-single timed sprockets with split taper bushing.
  • Drives: RC 80 Chain-driven. Variable frequency drives recommended for operating flexibility, included with controls system.
  • Auto Lube: Automatic oiler system for the drive chain including reservoir, solenoid, distribution manifold, copper
  • plumbing and adjustable brush applicators; easy sprocket, chain and bearing maintenance.
