Delta - Y Type Tank Bottom Valve

• Tank or reactor bottom outlet valve
• Tank bottom control valve

• Shutter: Disc or piston with vertical move Rising disc or Disc lowering into body to open
• Process/Atmosphere sealing with stuffing bow (repackable in service)
• Body designed for further flowing

Angle Stem Tank Bottom Valves provide actuator clearance on jacketed or insulated vessels.

Manufactured in stainless steel and carbon steel, in casting material,and fabricated.

• Flanged End Dimensions: ASME B 16.5
• SOCKET WELD END DIMENSIONS: ASME B 16.11
• SCREWED END DIMENSIONS: ASME B 1.20.1
• Valve Inspection& Testing: AS PER MANUFACTURER
