Aquatic - Model OSR-DM -Demineralisation Water Systems
Established in 2006, we have goal of providing high quality service worldwide. We are unique with combination of Knowledge & Experience in Water Treatment. We provide comprehensive spectrum of technologies for producing all grades of Water required in Testing Lab, R&D and Production. For laboratories, R&D, Production that do not have a reliable source of pure water, Aquatic Solutions offers compact water systems producing pure and ultrapure water directly from tap water.
This concept offers several benefits:
- It allows installation of a complete water system in minimum amount of space in any lab, R&D Centre, Production area with tap water feed
- It eliminates the need for central water purification systems and the associated water delivery loops which may be complex, expensive, and difficult to
- maintain and to extend
- It gives the users of the water system complete control over all water purification steps and the final water quality.
INSIDE OSR-DM
Pre-Treatment Systems
MultiGrade Sand Filter (OSR-MGF) is the first stage to DM unit, it filters out the suspended solids, silt from the inlet water. It consist of different layers of
sand media to ensure complete filtration. OSR-MGF prevents formation of silt layer, clogging & microbial growth on resin bed layer.
Advance 1st Stage Demineralisation
Demineralisation (OSR-DM), the second step removes 85-90% of ions and 99% of all dissolved organic substances and particles. Safety features like conductivity indicator & auto flushing valve are provided to ensure efficient working & lower maintenance. Once the calculated amount of demineralised water is extracted of DM Unit it has to be regenerated with acid/alkaline solutions. Our expert engineers are best to judge and suggest the quantity & duration.
Polishing 2st Stage Mixed Bed
Mixed Bed (OSR-MB), the third step removes 95-99% of ions and 99% of all dissolved organic substances and particles. Ultrapure Water of very low conductivity is achieved through this unit .Safety features like conductivity indicator & auto flushing valve are provided to ensure efficient working & lower maintenance. Once the calculated amount of demineralised water is extracted of MB Unit it has to be regenerated with acid/alkaline solutions. The quality achieved may vary from case to case basis, our expert engineers are best to judge and suggest.
Sterilization Ultraviolet Lamp (UV)
Water is Sanitize with a high dose of ultra violet light energy at a wave length of 254 nanometers destroys pathogenic microbes by affecting the DNA in the cell and multiplication of micro-organisms gets stopped with this they can`t reproduce. When we use UV with DM Technology, UV Technology provides additional sterilization to the water leaving no scope for bacteria. It is the final stage of purification system.
Salient Features:
- Flow Indicators with Batcher gives you exact quantity with alarm for DM Water Utilised
- Auto Operation features enable hassle free operation & regeneration
- Hot Water Sanitisation, Auto Flushing & Recirculation to avoid micro-organisms growth
- Additional Features like Storage Tank, Distribution Loop
- All Validation documents like DQ, IQ, OQ protocol, test certificated, material certificates, instrument calibration certificates etc provided
