Depac - Model Type 140 -Balanced Mechanical Seals
FromDepac
The type 140 is a dynamic, balanced mechanical seal. The outside mounted mechanical seal is useful above all where there is little space in the stuffing box - and has the advantage that no metal comes into contact with the medium. The type 140 is an inexpensive mechanical seal for use with aggressive media.
Most popular related searches
- Mounted outside
- Carbon face with stainless steel reinforcement
- Retaining ring is clamped to the shaft (a positive retention/support system required above 10 bar)
- No set screws
- No metal parts in contact with the medium
- Springs outside the medium
- Hastelloy C springs
- Balanced for a longer service life
- Welded bellows is self-cleaning
- Independent of the direction of rotation
- Use with various stationary faces possible
