DepacModel Type 140 -Balanced Mechanical Seals

FromDepac
SHARE

The type 140 is a dynamic, balanced mechanical seal. The outside mounted mechanical seal is useful above all where there is little space in the stuffing box - and has the advantage that no metal comes into contact with the medium. The type 140 is an inexpensive mechanical seal for use with aggressive media.

Most popular related searches
  • Mounted outside
  • Carbon face with stainless steel reinforcement
  • Retaining ring is clamped to the shaft (a positive retention/support system required above 10 bar)
  • No set screws
  • No metal parts in contact with the medium
  • Springs outside the medium
  • Hastelloy C springs
  • Balanced for a longer service life
  • Welded bellows is self-cleaning
  • Independent of the direction of rotation
  • Use with various stationary faces possible
