Eltek - Model GD84 -Differential Pressure Transmitters

The GD84 Differential Pressure transmitter targets clean room applications and allows differential pressure (+/- 250 pascal) to be monitored in a single compact transmitter. The precision diaphragm solid state sensor is automatically compensated for barometric pressure and is not affected by the mounting attitude of the transmitter. The high quality quick-disconnect connector system is used to attach 6mm internal diameter tubing. An LCD provides immediate readings of differential air pressure. Using licence exempt radio enables ranges of up to 300 metres in a built environment, or up to 2km with line of sight. The GD84 can be used with RX250AL/SC250 (Secure data CFR21 Part11) receiver loggers, RC250 receiver only and WSR, Wireless Sensor Receiver.
