Maha - Model C_MBT C 3.5 W220 VP 210152 -Digital Roller Brake Tester

Digital roller brake tester for cars and vans
up to 3.5 t axle load with 2 x 3 kW drive motors
and a max. track width of 2,200 mm

Particularly suitable as stand-alone tester
or as part of car reception and diagnostic test lanes

• Features: -Automatic aid for comfortable vehicle exit with
  • Real slip monitoring and automatic start-up delay as standard
  • Tyre-saving thanks to integrated automatic start-up monitoring
  • Automatic slip switch-off with pointer stop and automatic restart driven axles
  • Automatic switch-off after vehicle exit
  • Electronic, temperature compensated (neutral) strain gauge system
  • Internationally recognised TÜV report in accordance with VkBl 149/2021 (Germany)

• Further product advantages - for details see Sales Handbook:
  • A sturdy and solid design
  • Interface module in the floor assembly
  • Secure and digital data transmission
  • Modular control box set-up
• Multi-flexible display possibilities
  • Simple start-up
  • Simple maintenance and service
  • Safe operation
  • Optimised calibration and adjustment
  • Integrated and expandable software and/or interfaces

Configuration:

• Roller set model C W220
• Self-supporting, encased roller set (Compact)
• Continuously height-adjustable (245 - 300 mm)
• High-quality powder coating: anthracite grey, RAL 7016

Scope of delivery:

• Control box with integrated control unit
• Roller set C_MBT C 3.5 W220 with integrated interface module
• Pluggable cable harness 12 m

• Axle load (traversable): 3500 kg
• Min. track: 780 mm
• Max.track: 2200 mm
• Drive power: 2 x 3 kW
• Test speed: 5 km/h
• Measured value display: 0-8 kN
• Roller diameter: 202 mm
• Roller axle distance: 400 mm
• gG Fuse: 25 A
• Power supply: 3/N/PE 400 V 50 Hz
• Dimensions of roller set (L x W x H): 2320 x 680 x 280 mm
