iTEMP - Model TMT125 -DIN Rail Temperature Transmitter
Transformation of sensor signals into standardized digital output signals for all industries. Unsurpassed reliability, accuracy and long-term stability in critical processes over all industries. The configurable transmitter not only transfers digital converted signals from RTD and TC sensors, it also transfers resistance and voltage signals using FOUNDATION Fieldbus™ communication. High measurement point availability by means of sensor monitoring functions and device hardware fault recognition. Optionally, installation on DIN rail according to IEC 60715 or in a field housing.
-
Universal temperature transmitter for up to 8 input signals
-
Sensor monitoring: cable open circuit, short-circuit and wiring error
-
Device hardware fault recognition for reliable operation and easy maintenance
-
Galvanic isolation between fieldbus and sensor inputs and between the input channels
-
Ex-Certification: FM IS, NI; ATEX Ex ia, Ex na for intrinsically safe installation in zone 1 and as associated apparatus in zone 2
-
Independent installation of connected temperature sensors in zone 0
-
Transducer block `concentrator` and Multiple Analog Input Block (MAI) allow for effective and fast configuration of the relevant parameters
-
Temperature transmitter with 8 input channels and FOUNDATION Fieldbus™ protocol for converting various input signals into digital output signals
-
Input: Resistance thermometers (RTD), thermocouples (TC) resistance transmitters (Ω), voltage transmitters (mV)
-
DIN rail mounting as per IEC 60715 and with aluminum housing for field operation
-
Measuring principle
Rail transmitter
-
Input
8 x for RTD, TC, Ohm, mV
-
Output
FOUNDATION Fieldbus H1
-
Auxiliary power supply
9...32 V DC (FOUNDATION Fieldbus)
-
Communication
FOUNDATION Fieldbus H1
-
Installation
DIN rail / field housing
-
Accuracy
(Pt100, -50...200 °C) <= 0,33 K
(Pt100, -58...392 °F) <= 0,6 °F -
Galvanic isolation
yes
-
Certification
ATEX II2 (1G/D) G Ex ia IIC T4
ATEX II (1) GD [Ex ia] IIC
FM IS, NI /I/1+2/ABCD/T4
FM AIS/I,II,III/1/ABCDEFG
FMC IS, NI/I/1+2/ABCD/T4
FMC AIS/I,II,III/1/ABCDEFG
IECEx Ex ia IIC T4 [Ex ia] IIC
IECEx Ex nA II T4
NEPSI [Ex ia] IIC
NEPSI Ex nA II T4
