Sartrex - Dockside Radiation Monitoring System

This system has been installed at three sites in Canada: Canadian Forces Bases at Halifax and Esquimau, as well as at the Maritime Engineering Test Range, at Nanoose Harbour, BC. The DMS is an integrated system which consists of a sensor—and- alarm-suite (SAS) for radiation detection and a base station IBS) for remotely monitoring, analyzing and displaying dosimetry measurements. Radiation data captured at the doc-side by the highly sensitive SAS sensors are transmitted to the BS communication hub (CH), and then to several remote monitors (RMs) located in the local area at National Defense Headquarters, all using standard telephony technology

The SAS includes triply—redundant Geiger—Mueller gamma radiation sensors and a microprocessor which controls the operation of the SAS unit. It also includes an uninterruptible power supply which provides power for at least 8 hours in case of power-Radiation levels exceeding safe limits cause alarm indicators such a beacon, horn, and message player to activate. In addition, an anemometer is included to monitor local wind conditions. The BS and RMs utilize identical, interchangeable notebook computers for redundancy. The BS, itself consists of a docking station and a multiple serial port to which up to 8 external modems can be connected. This allows simultaneous data transmission between all stations. The laptop computers contain communication, analysis and data storage software, several warning and error correction facilities as well as a computer-based alarm system {visual, audio and recorded). The software continuously displays the dose rate in both graphical and digital formats.
