Dolycon - Model VFD -CT112 Series -380v/220v 3 Phase/1 Phase Solar Pump Inverter
CT112 series solar pump inverter applied in solar pump system can convert DC power from solar PV array to AC power to run pump motors. Inverter controls the system operation and adjust the output frequency in real-time according to the variation of sunlight intensity to realize the maximum power point tracking (MPPT).
Most popular related searches
solar pump inverter
solar pumping inverter
solar pump
solar water pumping
solar water pump
urban water supply
solar pumping system
solar pump system
water pump
water pump solar
- Item NO.: CT112
- Order(MOQ): 10
- Type: Solar Water Pump Inverter
- Control Mode: MPPT control
- Rated Power: 0.75kw to 1250kw
- Output Frequency: 0-600Hz
- Horsepower: 1hp - 1700hp
- Apply to all kinds of single phase or 3 phase AC induction motor.
- Equipped with TI DSP digital control technique and Infineon IGBT power integration module design.
- Maximum power point tracking (MPPT) algorithm for dynamic VI.MPPT efficiency can be 99%
- Fast response speed and good stability.
- AC and DC input available,but do not use DC and AC at the same time.
- Remote control,support RS485 protocol.
- Automatic sleep&awake function:
- Full protections:overload,over-current,over-voltage,under-voltage,short circuit,dry pumping etc.
- PV reversed connection protection.
- Widely applied in agriculture and forestry irrigation, desert control, solar pasture irrigation, grassland animal husbandry, urban water supply and other landscapes.
