Topas - Model 300 -Domestic Wastewater Treatment Plants

• family houses,
• recreational objects and cottages,
• hotels and pensions,
• restaurants.

wastewater treatment plants are delivered as complete products, including the lid without the necessity to purchase any additional adapters according to the depth of the inflow piping. For production of the skeleton frame of TOPAS wastewater treatment plants then polypropylene material is used which ensures the long term service life of the product.

In the Czech Republic wastewater treatment plants are certified by the SZÚ Brno testing laboratory (to see certificate – click here). At the same time, attestations or certificates have been issued from the following countries: Germany (Deutsches Institut für Bautechnik), Romania, France, Poland and Russia. The original technical solution of TOPAS wastewater treatment plants is protected by international patent No 282 411.

Description of activity

TOPAS wastewater treatment plants work on the principle of the treatment of wastewater by means of activated sludge in upward substances. The air that is necessary for the life of the micro organisms is provided by a small membrane air blower with silent operation which is located directly in the plant. The air blower together with the added three-way electric valve is also used to power the air pump which ensures the pumping of water between the individual chambers of the wastewater treatment plant.

Sizes of TOPAS wastewater treatment plants

TOPAS wastewater treatment plants are delivered in the following sizes:
T5, T8, T10, T15, T20, T30, T40, T50, T75, T100, T125, T150, T200, T250, T300

The number for the size of the wastewater treatment plant states the number of population equivalent (PE), for which the respective wastewater treatment plant is constructed. At present 1PE corresponds to the consumption of 150l of water per day.

TOPAS Standard version

• Biological waste water treatment plant with efficiency of 95%
• Patented principle of operation based on alteration of the flowing and regenerating phase
• Built-in sound and lighting signalling of emergency status
• Heat-insulated, steam-proof, removable cap
• Independent sludge tank for anaerobic stability of sludge
• Completely removable technology while servicing the water treatment plant
• Treated water can be discharged into water streams (river, streams, lakes)
• Water can be used for watering of vegetation (with the exception of dropping)

TOPAS Version with sand filterUnique technical solution of a waste water treatment plant

• Contains built-in sand filter for mechanical completion of the treatment of water at the outflow which during the regeneration phase is automatically washed several times during the day
• The efficiency of the treatment is higher than 98%
• The treated water can be used for penetration into the ground and underground water and for discharging into a rainwater sewerage system
• Recommended type for root and drop watering
