Graetz - Model GammaSmart Two -Dose Rate Alarm Unit
The GRAETZ GammaSmart Two portable dose rate alarmunit is specially designed for personal radiation protection when handling ionizing radiation. The rugged and battery-powered measuring device even fits comfortably in jacket or trouser pockets in its compact form.
Most popular related searches
non-destructive testing
personal radiation protection
personal radiation
radiation protection
dosing system
water protection
NDT test
NDT testing
ionizing radiation
personal protection
- Robust and compact aluminum housing
- Fits in jacket or pants pocket or can be attached with the integrated clip
- Clear visual and audible warnings when a dose rate warning threshold is exceeded.
- Dust and splash water protection (protection class IP54)
- Also available as special version for the field of non-destructive testing (NDT)
- The GammaSmart two device is a very robust, pocket-sized, battery-operated dose rate warning device for personal radiation protection
- It detects gamma and X-ray radiation and reports these with clear optical and acoustic single pulses, which increase in the pulse sequence as the dose rate increases
- The splash-proof aluminum housing (IP54) provides shielding against electromagnetic influence, an optical battery control indicates the operational readiness of the device
- A plastic clip is used to attach the dose rate warner to clothing
Optional:
- GammaSmart two V40 with a dose rate warning threshold at 40 µSv/h for use in non-destructive testing (NDT) radiographic testing. For mobile handling, the local dose rate must not exceed 40 µSv/h.
- Max. permissible dose rate: 1 Sv/h
- Sensitivity: approx. 6 imp/min at 3 µSv/h
- Energy sector: approx. 35 keV – 1.3 MeV
- Dose rate warning thresholds: optional 1, 40 µSv/h for version V40
- Dimensions: approx. 59 × 71 × 30/17 mm
- Weight (incl. batteries): approx. 90 g
- Protection class: IP54 (Protected against splashing water)
