DRAINEX - Kerb Side

• Produced and tested according to EN 124
• Cover and frame: ductile iron, with cut flange
• Clatter-free due to elastomer insert integrated in the grating
• Spring locking bar
• Optional: 2-bolted grating

For versatile usage suitable for all traffic loads up to D 400.

Rectangular gully grating, dimension 601 x 406 mm, produced and tested according to EN 124, class C 250/D 400.  Grating and frame: console type, made of ductile iron; clatter-free with elastomer insert and spring locking-system integrated in the grating.
Frame height 75/100 mm; total weight: 38,0 / 59,0.
