Drifter Technology Co., Ltd.
Drifter - Model MINI WAVE BUOY CX-50D -Hydrodynamic Monitoring Technology
Ultra-lightweight design and perfect sea surface following capability. Wave statistics are transmitted in real-time. Compact in size, easy to deploy and retrieve. High sensitivity with sea surface wave motion. On board processing of wave statistics. Satellite data transmission. Retrieve data anywhere through web access.
Most popular related searches
Physical Dimensions
- Size : 500x500x325 ±10 mm
- Weight : Approx. 5 kg (W/O Battery)
Onboard Sensors/ Processor
- GPS/GLONASS Positioning System : Position 2.5 m CEP Velocity ± 0.1 m/s
- Water Temperature Probe | ± 0.1°C :
- Wave Motion Detector : 3-Axis Acceleration Pitch, Roll & Yaw in 10 Hz for 10/20 Minutes
- Wave Processor : Significant Wave Height Mean Wave Period Mean Wave Direction Peak Wave Period Wave Directional Spectrum
Communications
- Iridium Satellite : Worldwide Coverage
Data Sampling
- Current : Sample/10 minutes (Default)
- Wave : Sample/20 minutes (Default)
Miscellaneous
- Data Logger Storage : 8 Gb -1 Year Raw Data Storage (Depends on Setting)
- Battery Life: Approx. lyear (Depends on Setting)
- Housing : Fiberglass Enhance Polypropylene
- Buoyancy : Approx. 30 kg (Default EVA Foam)
