Eurotron - Model T650M-MK2 -Dry Block Temperature Calibrator for Marine Applications
The T650M-MK2 is a fast, time-saving, cost effective calibrator designed specifically for the maritime industry and engines technician. The T650M-MK2 holds a DNV type approval.
Most popular related searches
- Range: Tamb+ 15 ºC to 650 ºC
- Calibration Insert : Ø 26 mm /Depth 150 mm
- DNV approved
- Approval: DNV Certificate TAA00002CY Rev 1
- Range: Tamb + 15 °C to 650 °C
- Accuracy: ±0.5°C @ 600 °C
- Stability: ±0.3°C full range
- Resolution: 0.1°C/0.1°F full range
- Display: 2 lines LCD-°C or °F user-selectable
- Block Diameter: 26 mm
- Immersion Depth: 150 mm
- Calibration Insert: Ø 26 x 150 mm ( easy interchangeable)
- Standard Insert: Insert A , 4 holes : Ø 3,2-5-7-10,5 mm
- Insert Material: nickel-plated brass
- Heating Time: 50°C to 650°C in 40 min including stabilization time
- Cooling Time: 650°C to 100°C in 70 min
- Ramp: Yes programmable, 0.1÷10°C/min
- Switch test: Yes with automatic capture/saving of contact close/open- 5 VDC
- Interfaces: RS232
- Power Supply: 115/240 VAC ± 10% 50/60Hz
- Power Consumption: 600 W
- Size: 130 x 260 x 280 mm (H x W x D)
- Weight: approx. 6.5 kg
- Scope of supply: Temperature calibrator, standard insert A, tool for insert removal, switch test
- leads, instruction manual, calibration certificate
- Fast heating and cooling
- High Stability
- Built-in stand alone temperature switch test function
- Fully on-board programmable temperature ramp
- Removable inserts, drilled to your requirements
- Rugged and hard-wearing enclosure
- 115-240 VAC switchable power
- Extremely portable and only 6.5 kg weight
- RS232 PC interface
- On-site re-calibration function
- Standard calibration certificate
