AUTOL - Model ADP120 -Dual-Line Lubrication Pumps
As a new generation of centralized lubrication systems developed by Autol Technology through long-term market research and technological innovation, the progressive centralized lubrication system can grease all parts to be greased in proportion through the progressive method, so as to meet the different consumption requirements of grease at different parts. It is suitable for medium and large excavators and other construction machinery and equipment.
Most popular related searches
Lubrication Pump
The lubrication pump consists of a grease drum assembly, a pump base, a motor reducer assembly, a plunger assembly, a shuttle block, an impeller, a liquid level assembly, and a monitor.The lubrication pump operates according to the control logic and time set by the monitor.
Monitor
The motor inside the lubrication pump drives the shuttle block and plunger to reciprocate through the reducer and pumps the grease in the drum to a lubrication line through a check valve and the pressure switch successively.
- Model : ADPB20L
- Capacity : 20L
- Max. pressure : 35 MPa
- Pump capacity : 20 ml/min
- Rated voltage : DC24V
- Storage temperature : -45°C ~ +80°C
- Operating temperature : -30°C～+70°C
- Recommended fuse : 15A
