HYPER VALVES - Dual Plate Check Valve
At Hyper Valve we are manufacturing Dual Plate Check valves with high quality Standards. We can offer valves in Cast carbon steel as well as cast stainless steel material. Wafer type, Lug type and flange end connections can be offered. Special material valves can be offered if required. Metal seated stellied trim as soft seated trim with PTFE or any rubber material are also available on request. They are the good choice for the applications where the water hammer effect is persisting. We offer this product in different size ranges and set pressure ranges.Most popular related searches
wafer dual plate check valve
check valve
water hammer
pressure reducing valve
paper mill
pipe system
pressure reducer
automatic valve operator
industrial mill
pulp mill
- Sugar mill.
- Marine & Mining.
- Distillery Plant.
- Fertilizer Plant.
- Pulp & Paper mill.
- Industrial Chemical Piping.
- Oil, Gas, Petrochemical Plant.
- Textile and Process Industries.
- Thermal and Nuclear Power Plant.
- Size: 2" to 24" (DN 50mm to 600mm)
- Rating: 150#, 300#, 600#, 900#, 1500#, 2500#
- End Connection: Wafer End, Wafer Lug End, Flanged End
- Seat Material : Metal to Metal, Soft Seated
- Design Type: Retainered , Retainerless
- Material: CF8, CF8M, WCB, CI, DI, Duplex steel 4A, 5A, 6A, Aluminium Bronze, Hastelloy C
- Dual Plate Check Valve as the most efficient & versatile design.
- This valve is suitable for low-velocity applications with infrequent velocity reversals.
- This design offers the twin advantages of No Water Hammer and NonSlam together.
- Dual Plate design minimize valve cracking pressure and reduces valve pressure drop.
- Spring loading on plate assists valve closing to ensure a tight seal and minimize slamming.
- When the flow decreases, the plates close by the action of torsion spring before flow reversal takes place.
- Dual Plate Check Valves are automatic in operation and designed to prevent reversal of flow in fluid piping systems.
- These valves are maintained open by the flow of fluid in the straight direction and are closed by the back pressure of the fluid.
- The valve can be fitted with external weights to allow the faster closure to reduce water hammer or shock pressure on flow reversal.
