Duplex - Model S31803 -Steel Pipes

Piyush Steel is a manufacturer, exporter, and supplier of Duplex Steel UNS S31803 Pipes, which gives better corrosion resistance in the adverse environments. These pipes show properties of both ferritic and austenitic stainless steel. These pipes can be supplied in made to order dimensions, different specifications, designations, and standards. These pipes used in mainly in the commercial, industrial and engineering applications. These pipes are supplied in the annealed condition offering higher strength in impact loadings. The properties of these pipes are achieved by means of having an overall content than similar performing austenitic and ferritic grades. This makes it most cost effective options for many applications. We use only advance machines and equipment to fabricate these products, thus making it more precise and accurate. Because of this, it is used in many critical and demanding applications.

About Duplex Steel UNS S31803 Pipes-

Duplex Steel UNS S31803 Pipes offer higher corrosion resistance. These pipes are designed for elevated strength and readily fabricable. These pipes have good anti-oxidation properties in the saline water. These pipes have great stress corrosion cracking resistance and local corrosion resistance in reducing and oxidizing environments. It has balanced alloying chemistry which offers improved corrosion resistance and workability. Importantly, these pipes not recommended to be used in the applications above 300 deg C temperature. Duplex Steel UNS S31803 grade is well known for its elevated fatigue strength. In this reverse bending stress arrived at the room temperatures. The fatigue limit is same as yield strength. For example the fatigue strength is closed with the corrosion rates; because of this fatigue strength is lowered. Due to this reason, these pipes are a good option over traditional grades. These pipes offer elevated strength at the moderate temperatures in the lower temperature ranges. In this stress relieving operation is performed in the temp between 525- 600 deg C. because of this process the resistance in the severe environments increased.

Our quality norms-

Our quality policy is to satisfy customer’s needs and expectations. We have continually improved the effectiveness of the quality management systems, sets quality objectives and plans. Moreover, we are committed to upgrading the capabilities of technical and working staff through training programs and continuous technical quality awareness. We have achieved high quality through the hard work of our professionals. Every single employee here is responsible for the quality of their work. All Piyush steel products are tested according to internationally recognized standards by more stringent internal test procedures which are developed for the application in the harsh field conditions. In addition to this, we perform different destructive and non-destructive testing on products.

Destructive testing-

• Thermal performance test
• Mechanical test
• Tensile test
• Hardness test
• Pressure test
• Compression test
• Leakage test

Non-destructive testing–

• Pitting corrosion test
• Micro test
• Macro test
• Radiography
• PMI test
• Intergranular corrosion test
• Chemical test

All the tests are performed on the special testing section and we provide some documentation reports along with delivered products that assure our quality. The reports include mill test reports, QAP, raw material test report, disinfection reports, welding guide, NABL test report and more. To provide products in 100% safe mode we use prominent packaging material and techniques such as wooden cases, plywood cartons, boxes. Also, we supply these in the form of bundles with the additional support of end caps. It is individually wrapped in a film of plastic that adds protection from contamination.

Markings On The Duplex Steel S31803 Pipes

The full identification of the pipe should be continuously marked down its whole length, including :

•   Nominal Pipe Size (Nominal Bore)
•   Schedule (Wall Thickness)
•   Specification
•   Grade
•   Method of Manufacture (Seamless or Welded)
•   Heat Number
•   Manufacturer’s Name or Symbol

• Pipe Specification : ASTM A790, A358 / ASME SA790, SA358
• Dimension Standard : ANSI B36.19M, ANSI B36.10
• Outside Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock
• Thickness Range : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
• Type : Seamless / ERW / Welded / Fabricated Pipes
• Form : Round, Square, Rectangular, Oval, Hydraulic Etc
• Length : Single Random, Double Random & Required Length
• End : Plain End, Beveled End, Treaded
• End Protection : Plastic Caps
• Outside Finish : 2B, No.4, No.1, No.8 Mirror Finish for Duplex Steel Pipes, Finish as per customer Requirements
• Delivery Condition : Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
• Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
• Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
• Specials : Sizes and Specifications other than above can be manufactured on request

• Petrochemical Industry
• Chemical Industry
• Oil and Gas Industry
• Pulp & Paper Indusry
• Power Plant Industry
• Food Processing Industry
• Pharmaceuticals Industry
• Energy Industry
• Aerospace Industry
