Pro-Uni - Model UM -Duty Cycle Electric Actuator

SHARE

Power supply: AC100~240V / DC24V / AC24V. Equipped with electric circuit protection device, to replace the fuse function.

Most popular related searches
electric actuator
position indicator
waterproofing
  1. Ambient temperature: -10°C~+55°C
    1. Humidity: 10%~90%
  2. Motor: Brushless DC electric motor (BLDC motor)
  3. Motor power: 30W
  4. Limit switch: SPDT 250VAC / 3A*2pieces (On/Off)
  5. Extra limit switch (Dry contact): SPDT 250VAC / 3A*2pieces (On/Off)
  6. Cable gland: 1/2" PF*1pc
  7. Indicator: Mechanical type position indicator
  8. Ingress Protection Rating (Waterproof): IP67
  9. With overload torque protection
  10. Manual overrid: When the power failure, rotate the override (by 8mm wrench) to turn on/off.
    1. ***Do not rotate manually with force and avoid quick rotating***
  11. Material of enclosure:
    1. Standard: Nylon / Optional: Aluminum
  12. Rotary type: Quarter turn 90°± 5
  13. Duty cycle: 100%
  14. Rated torque: 75%
  15. Flange/Mounting type: ISO5211, F03/F04/F05/F07
    1. Bushing: Standard 14*14mm / Optional: 9*9mm and 11*11mm
  16. Wiring diagram:
