Vector CSM - E-Mobility Measurement System
The Vector CSM E-Mobility Measurement System is a modular toolbox of closely harmonized hardware and software for the development of all types of electric and hybrid vehicles. Through consistent protocols, tailored interfaces and flexible expansion options, it can be scaled for many measurement tasks.
The Vector CSM E-Mobility Measurement System contains all necessary hardware and software to perform measurement and testing tasks for eMobility. Therefore it includes:
- Measurement modules, interfaces and software for the acquisition and synchronization of large data volumes of:
- Analog measurement data from high and low voltage environments
- Measurement data from vehicle buses
- Data from control units
- Data logger for recording analog measurement data and data from vehicle buses
- The eMobilityAnalyzer for performance analysis and other calculations in real time
- Software solutions for data analysis and data management
- Decentralized, scalable measurement system for vehicle and test bench with high-performance E-Mobility online analysis
- Extremely compact, robust and interference-free measurement modules for HV and low voltage environments
- Synchronous acquisition of measurement data from measurement modules, vehicle buses and control units
- Direct measurement of current and voltage in high-voltage cables with up to 1 MHz
- Multi-channel real-time performance analysis
- Raw data recording, powerful signal analysis and evaluation including data mining
The components of the E-Mobility Measurement System are structured into different expansion stages, which can be combined according to the specific application.
The robust and compact design of all components makes the measurement system ideal for mobile use on test drives and also on test bench.
The E-Mobility Basic Measurement System is the core of the measurement system. This expansion contains all the measurement technology you need for the most common measurement and testing tasks.
Measurement Modules and HV Breakout Modules- HV Breakout Modules
- Measurement of current, voltage, power and shield currents
- Measurement directly in the HV lines increases the accuracy of the measured values
- CAN MiniModules, EtherCAT®- and XCP- based measurement modules for measurements in the high-voltage and low-voltage environment, such as:
- Temperature
- Acceleration
- Strain
- Torque
- Vibration
- Flow rate
- Moisture
- and much more
- The connection and synchronization of all measurement modules is established either via separate interfaces or a corresponding option for supporting measuring modules
- Synchronization of all measurement data acquired with EtherCAT® better than 1 µs
- Acquisition and bundling of CAN measurement data
- PTP time synchronization according to IEEE 1888 standard
- CANape and vMeasure are software packages for data acquisition and visualization
- Integrated eMobilityAnalyzer function library for powerful real-time analysis:
- DC and AC power analysis
- Efficiency analysis of an electric motor
- Efficiency measurement
- Charger efficiency analysis
- Analysis of current and voltage ripples
- Parallel acquisition of the most important values in the high-voltage and low-voltage environment
- Easy combination of CAN- and EtherCAT®-based measurement technology
- Powerful real-time analysis
- Easy scalability for different measurement applications
