Ebitt - Model NRC -Inline Type Centrifugal Pumps
Close-coupled, single-impeller, centrifugal pumps; electric motor connected to the pump by rigid coupling. Pump casing with suction and delivery connections with the same diameter and on the same axis (in-line). Main dimensions of casing complies with EN733. These pumps are directly coupled to electric" motors that comply with ILC frames and VOl norms. Connections: Flanges PN 16, LN 1092-2.
Most popular related searches
single impeller centrifugal pump
centrifugal pumping
centrifugal pump
fire fighting system
impeller centrifugal pump
coupled pump
air conditioning
centrifuge
fire fighting
water supply
- For clean liquids, without abrasives, which are non-aggressive for the pump materials (contents of solids up to 0.7%).
- For heating, air conditioning, cooling and circulation plants.
- For civil and industrial applications.
- For water supply and fire fighting systems.
- Other voltages.
- Protection iP 55.
- Eff.-l class electric motor.
- Special mechanical seal.
- Special material combinations for different applications. (e.g. bronze or AISI304 - 316 stainless steel.)
- CFRAM X coating of hydraulic parts for chemically agressive or mechanically abrasive fluids, especially sea water. Higher or lower liquid or ambient temperatures.
- liquid temperature from 10°Cto+ 110°C
- Ambient temperature up to 40 "C
- Total suction lift up to 7 m.
- Maximum permissible working pressure up to 10/16 bar.
- Continuous duty.
