ECS - Model ATS 75.110 -Automatic Horizontal Channel Baler

This type of baler is designed for baling corrugated trim, newspapers, magazines, cardboard, plastic, packaging, alum-foil, thin alum-sheet and cans.

• The ram chamber is deep and narrow providing efficient shearing of these types of material.
• Feeding and conveyors are controlled by photocells in the hopper.
• Feed hopper size options of 160 x 70cm or 130 x 70cm and with the addition of pre-press flaps this increases the width to 80cm.
• The bale length is controlled by the length control wheel and/or by the number of strokes.
• Bales are tied in 5x horizontal direction.
• There is a choice of single material control system or multi-material (up to 20) including proportional pressure control. The operator has the option of selecting any of the pre-set programmes for automated operation or if required these settings can be adjusted and stored manually.
• Press chamber can be made of wear-resistant sheet metal.
