Efcon - Bubble Tube Flowmeter
FromEfcon Water B.V.
Sampling systems with open channel flow measurement can be equipped with a level sensor (bubbler tube sensor, or an external 4-20mA signal) and can be used for the following primary devices:
Most popular related searches
open channel flow monitoring
channel flow monitoring
open channel flow
flow monitoring
open channel flow monitoring system
level sensor
air pump
flow monitoring system
water flow monitoring
water level monitoring
- V-Notch: V-notch measurement, for 3 standard angles (28,3°, 53° & 90°).
- Venturi: According formula:
- Formula 1: According formula: Q = C × √h3× 3600
- Formula 2: According formula: Q = C × he × 3600
- Data table: Assign 24 medium levels (mm) to 24 flow (in m3/h)
* Open channel, on water level base flow measurement are based on international leading standards like: ISO 1438 & BS 3600
Bubble tube measurement
When selected the air pump for the bubble tube starts creating pressure. Standard range (full scale): 0-0,5 meter.
