Forrec - Model TQ 1300 -Electric or Hydraulic Four Shafts Shredders
The use of four-shaft shredders (TQ) increases the solid waste treatment operating possibilities. In fact, they combine the reliability and power of the double-shaft shredders with the possibility of controlling the output material size. Built for heavy-duty use, TQ series shredders are the result of an innovative design that aim to create efficient and flexible machines. the exclusive and innovative interchangeable shaft system and the use of wear-proof screens have drastically reduced the management and maintenance costs.
- Low number of rotations (10-12 rpm)
- Four shaft system with independent engines and reducers
- Configurable automatic gear reversal
- Bearings outside of the cutting chamber
- Automatic greasing managed by PLC
- Use of high quality steels
- Configurable blades for thickness and number of teeth
- Wearproof grilles to define the material being output
Overall Dimensions:
3400 x 1800 mm H=3800 mm
Version:
electric / hydraulic
Cutting chamber dimensions:
1260 x 1320 mm
Blades:
standard
Weight:
12000 Kg
Blade thickness:
50 mm / 60 mm
Motor drive:
2x22 + 2x30 kW / 2x30 + 2x37 kW
Grilles:
configurable from 30 mm to 120 mm in diameter
- Plastic
- Wood
- Paper/cardboard
- Oil filters
- Refrigerators
- WEEE
