Unify Electronic - Model REP - 100 EMCSA -Electronic Regulator

The command REP-100 is born for controlling proportional valves with one solenoid valves open loop ie those that do not have internal positioning of  the transducer. The REP100 device is a  microcontroller that thanks to this technology,  `DIGITAL`, you can drive any type and brand of proportional valve, a voltage between 10 and 30 Vdc and a current between 0 and 2500mA. Adjustment of the current and ramps is done via a PC or handheld programmer software  GAMMA1.32 SUITE PES93C46. The controller is integrated into a completely sealed metal box with IP67 protection.
