Elite - Model TMH12 -Multi-Zone Tube Furnace
The TMH12 furnace is a bench mounted tube furnace ideal for most general laboratory thermal processing applications. High grade resistance wire elements wound onto a ceramic worktube which is an integral part of the furnace. Vertical versions are available which have a separate temperature console.
Most popular related searches
tube furnace
single-zone tube furnace
furnace
digital temperature controller
laboratory furnace
thermocouple
multi-gas
process gas
- The TMH furnaces are designed to give a longer uniform centre zone temperature than that of the single zone tube furnace models.
- All TMH models are controlled by retransmission of set point from the centre zone controller to the end zone controllers.
- Independent control of each zone is also available.
- Low thermal mass insulation used throughout for maximum thermal efficiency and stability.
- Protective outer mesh covers for improved operator safety.
- `N` Type Thermocouples are used in these furnaces.
- High end Microprocessor PID controller.
- Horizontal models are supplied as standard with controls in the base.
- Work tubes of various materials, lengths and diameters for use in the furnace.
- The work tubes are available for containment of atmosphere or protection against process contaminants.
- A variety of end seals for work tubes to allow processing under vacuum or gas atmospheres.
- Multi segment, multi program storage controller.
- Over temperature protection controller.
