Environmental Sensors Company

- Model Z-500XP - Portable Desktop Carbon Monoxide Meter



Environmental Sensors Co.'s Carbon Monoxide Meter is a portable desktop instrument that measures carbon monoxide concentration in a range of 0-300 ppm and a resolution of 0.1 ppm. The instrument makes it possible to monitor carbon monxide vapor in air. The insturment has an LCD display giving concentrations in ppm every 10 seconds, a low battery indicator, and an audible alarm that can be set at any level from 0-300 ppm. With the touch of a button, the meter displays STEL (average of every 15 min.), TWA (8 hour average) and Peak. The internal pump makes it possible to sample from hard-to-reach areas or confined spaces by attaching a flexible tube to the meter.

  • Portable
  • Internal Pump
  • Rechargeable Battery
  • Remote Sampling
  • Simple to Use
  • TWA, STEL and Peak
  • Audible Adjustable Alarm
  • Data Logging

The Z-500XP meter stores all of the exposure points for up to 5 logs (a log is created in the instrument's internal memory each time it is used). A log contains: date, time, number of exposure points, the interval between each point, and the actual exposure points. All of the log files can be easily uploaded to PC using components vailable within the Microsoft Windows Operation System or the termianl software included with the instrument.

The sensing element of the instrument is an electrochemical cell. The cell is a four-electrode type, which contains a working and an active auxiliary electrode. The signal from the auxiliary electrode is used for temperature compensation and to improve the selectivity of the entire sensor. The sensor response is linear with the concentration of the target gas in air.

  • Nominal Range: 0-300 ppm
  • Maximum: 2000 ppm
  • Sensor Life: > 2 years
  • Resolution: 0.1 or 1 ppm
  • Min. Detectable: 0.1 or 1 ppm
  • Response Time: < 30 sec.
  • Warm-Up Time: 60 sec.
  • Operating Temperature: -20 °C to 50 °C
  • Pressure Range: Atm ± 10%
  • Relative Humidity: 15 - 90 % non-condensing
  • Alarm: Audible 80db
  • Dimensions: H x D x W: 7.5' x 5.75' x 2.75'
  • Weight: 900 grams
  • Battery: Internal rechargeable Battery or AC Adaptor
  • Warranty: One Year
