Esimtech - Model ESIM-FWS3 -Workover Simulator

SHARE

The ESIM-FWS3 Workover Simulator is a full-size training system designed to replicate the mechanics and dynamics of major and minor workover operations in the oil and gas sector. The system encompasses a comprehensive suite of hardware components, including a workover console, BOP console, and choke console, all constructed with durable metal to simulate real operational environments. It features advanced parameter and scenario display systems backed by LED and graphics processors. The software suite offers extensive functionalities for training, including modules for student management, system diagnostics, and real-time parameter monitoring. Training scenarios cater to various skill levels, covering primary, intermediate, and senior operations. The system uses sophisticated mathematical models for simulating pressure, torque, and flow rate, allowing trainees to practice in a virtual environment that mirrors real-world conditions. Customized settings enhance the flexibility and depth of the training experience.

Most popular related searches
pipe ramming
choke manifold
simulation training
standpipe manifold
mud pump
standpipe

Major Hardware

Full-size workover simulation training system is composed of workover console, BOP console, choke console, standpipe manifold, choke manifold, kill manifold, remote console, parameter displaying unit, and scenario displaying system. The hardware devices all simulate the real site devices, which represent the workover operation environment.

Workover console

Work-over console simulates the standard XJ45 driller console. The control and display are the same as real equipment. It can simulate draw-works raising and lowering, mud pump speed regulating, etc.

  1. All metal construction (steelconsole and aluminum panel);simulating XJ45 work-over rig, with band brake system; suitablefor major and minor workover operation.
  2. The size is 1110mm*560mm*1250mm

BOP console

BOP console resembles conventional products. The operations and parameter displayare the same as real equipment.

  1. All metal construction. The size is 860mm*530mm*1870mm;
  2. Adopting “annular-pipe-ram-blind-ram-pipe ram” structure, linked with remote console.

Choke console

Choke console resembles conventional products. The operations and parameter display are the same as real equipment

  • All metal construction (steel console and aluminum panel);the size is 610mm*830mm*1120mm;
  • Adopting dual hydraulic pressure choke console structure.
