ETSP - Model TV and THV Series -Altitude Chambers
FromETSP Co., Ltd.
For performing altitude and climatic (temperature and humidity) testing in one combined test chamber. More than one condition can be created simultaneously to satisfy many types of test requirements. Altitude temperature chambers, Altitude temperature and humidity chambers.
Most popular related searches
temperature chamber
test chamber
rotary pump
demineralization unit
chart recorder
humidity chamber
water cooling
humidity testing
safety system
reverse osmosis system
- Slient compressors using ecologically friendly refrigerants.
- Air temperature variation and quick adaptation of specimens to it
- Friendly, flexible, up-to date control and management systems.
- Allows easy servicing and upgrades.ode.
- Temperature range
- -40 ? ~ +180 ? (single stage refrigeration system)
- -70 ? ~ +150 ? (changeable according to user`s demand)
- Temperature accuracy: Less than ± 0.3 ?
- Temperature fluctuation: Less than ± 0.5 ?
- Humidity range: 20% ~ 98% RH(10% ~ 98% RH is an optional spec)
- Humidity stability: Less than ±2% RH
- Humidity uniformity: Less than ±3% RH
- Heat-up rate: More than 3 ?/min
- Pull-down rate: More than 2 ?/min
- Vacuum pump: Two stage oil rotary pump or dry pump
- Condensing: Air cooled or water cooled type
- Input power requirements: 220V/380V, 50Hz/60Hz, 1Ph/3Ph (Changeable according to customer specification)
- Viewing window (heater wire including, reinforced window) and interior light
- RS232/485 oven networking With control software
- Caster for moving
- Oil mist trip
- Spare parts kit
- Instruction and maintenance manual
- Low humidity kit
- Chart recorder
- Port hole
- GN2 purge
- Demineralization unit (RO system)
- Customization available
