Ruilong - Model YL200 -Factory Borehole Drilling Machine /water well drilling rig for Sale 200m
Supply Ability Supply Ability 10 Set/Sets per Week Packaging & Delivery Packaging Details 1. CTN carton 2. wooden boxMost popular related searches
water well drilling rig
water drilling rig
water well drill
water drilling
drilling rig
well drilling
water well
water well rig
well water drilling
borehole drilling machine
Drilling depth 30--200m
Max open hole dia. 300mm
End hole dia. 75mm
Drill rod caliber 60mm
Drilling angle 90°~75°
Drilling rig move stroke 300mm
Drill weight (Not include power) 975kg
Spindle speed 64,128,287,557r/min
Spindle stroke 450mm
Max.lifting capacity 2400kg
Single line lifting speed 0.41, 0.82, 1.64m/s
Wirerope dia. 13mm
Winch roll capacity 35m
Brake band dia. 260mm
Brake band width 70mm
