Sony - Model IMX252 -Fast Mono Industrial Camera
Small dimensions: 26 x 26 x 31 mm, 30 grams, 3.1 Mpix Monochrome Sony CMOS Pregius™ at 218 fps @8bit, Flat ribbon flex cable ideal for Multi camera setup and Embedded vision, PCI Express Gen2 Compliant. 2K camera Applications: Ultra-fast 3D scanning, Miniature and accurate robotic arms, Industrial and Factory Automation, Machine Vision, High definition Motion capture, Cinematography and Entertainment, 360 Panorama, Face recognition, Eye Tracking, Body scanner, People counting, Broadcasting, Sports Automation & Motion Tracking, Rapid process capturing, e.g. golf club swings, baseball, tennis, hockey, VR and AR (virtual or augmented reality), Autonomous vehicles
Part Number: MX031MG-SY
Resolution: 3.1 MP 2064 x 1544
Frame rates: 218 Fps
Sensor model: Sony IMX252
Sensor type: CMOS Matrix B/W
Sensor size: 1/1.8"
Sensor active area: 7.1 x 5.3 (Diagonal 8.9 mm)
Readout method: Global shutter
Pixel size: 3.45 µm
Digitization: 8, 10, 12
Data interface: PCI Express Gen2 (PCIe)
Dynamic range: 70.9 dB
Full Well Capacity: 9900 e-
On-chip binning: 1x2 (and 2x2 Skipping)
Dark current: 2.1 e-
Readout noise typ.: 2.32 e-
Signal to noise ratio: 40.3 dB
Exposure range: 1µs to 30sec, in steps of 5.29µs
I/O Ports: GPIO IN, OUT
Power consumption: 3.7 Watt
Lens mount: C or CS Mount
Weight: 30 grams
Dimensions WxHxD: 26 x 26 x 31 mm
Operating temperature: 50 °C
