Integrated Optics MatchBox - Model 405 nm -Fiber-Coupled Diode Laser Module

Fiber-coupled 405 nm diode laser module is a robust and handy unit for alignment-free operation throughout the lifetime of the laser. Proprietary fiber coupling technology ensures good power stability and excellent fiber-coupling efficiency. An end-cap is provided against degradation of the fiber tip inside the module thus, up to 100 mW of power can be coupled into the fiber. FC/PC connector is provided as a standard and the pigtail length is approx. 1 m. Other connectors are available as well. By default, this type of laser is built with FC/PC connector, but other fiber terminations are available upon request. Details about non-standard connector and the fiber used with it should be discussed with the Integrated Optics sales team.
