VIG Industries -ย Model 200/1 -FID Methane/Non Methane (NMHC) Oven Heated Hydrocarbon Analyzer
The VIG Industries, Inc. Model 200/1 is a microprocessor based, oven heated methane / non methane (NMHC) hydrocarbon analyzer for high accuracy, sensitivity and stability. The Model 200/1 measures methane and non methane hydrocarbons at preset intervals. The VIG Model 200/1 uses one(1) Flame Ionization Detector (FID) to obtain methane and non-methane hydrocarbon readings. A sample is fed to the analyzer via an internal heated pump. After the sample reaches the analyzer, a portion of the sample is trapped and fed through a GC (gas chromatography) column to separate the methane from the total and is fed to the FID detector for analysis. As soon as the methane is read, the remaining sample is back flushed through the GC column and fed to the FID detector for analysis of the non-methane component. The LCD display indicates the amount of methane and non-methane hydrocarbons.
The Model 200/1 utilizes one flame ionization detector (FID). The detector, all sample lines, GC column and all solenoid valves that come in contact with the sample are maintained in a controlled, heated oven to prevent condensation, and to provide reliable performance in the analysis of concentrations of wide varieties of hydrocarbons in gaseous mixtures and in ambient air.
- Compliance Monitoring - US EPA Method 18
- Process Monitoring - Continuous monitoring and alarm or control of:
- Process gas streams utilizing organic solvents
- Crude oil
- Other chemicals containing hydrocarbons
- Efficiency Monitoring - Monitoring effluent of volatile organic compound (VOC) reduction equipment for:
- Environmental compliance
- Efficiency control of incinerators (Thermal or catalytic)
- Scrubbers
- Carbon absorbers
- Monitoring of catalytic converters
- Other abatement equipment
- Safety Monitoring - Lower explosive limit (LEL) monitoring and/or control of:
- Ovens/dryers
- Fugitive emissions monitoring
- Personnel work area monitoring
- Leak detection of process equipment or solvent storage areas
- Stack Monitoring
- Easy to use software
- GC technology used for separation
- Automatic startup / ignition
- Automatic fuel shut-off system
- Automatic flame-out indicator
- Adjustable alarm and oven settings
- Precision 1% of full scale
- Fast response
- Methane and Non methane - minimum 2.5 minute cycle
- Two stage sample filter with exchangeable sintered stainless steel elements
- PTFE isolated detector (FID)
- 19" rack or bench mount
- Heated sample pump head
- Outputs 0-1, 0-5, or 0-10Volts
- Automatic ignition
- Zero and calibration input ports with software
- 4-20mA output - no extra charge
- Range recognition relays
- RS-232 interface
- Internal combustion air supply
- Automatic sample shut-off system
- External zero air generator (reduces bottles)
- Hydrogen Generator (reduces bottles)
- Heated sample lines and controllers
- Strip chart recorders and data loggers
- NEMA rated enclosures
- Fuel : Hydrogen (UHP Grade) @ 18psi incoming pressure
- Combustion Air : Zero Grade Air @ 18PSI
- Operation Air : Compressed Air (Instrument Air - Dry / Oil-Less) @ 60PSI
- Zero Gas : Zero Air (UHP Grade) @ 10PSI
- Calibration Gas : User Selected @ 10PSI
- Carrier Gas: Nitrogen (UHP Grade) @ 30PSI
- Power : 115Vac, 60Hz or optional 220Vac, 50Hz
- Ambient Temperature : 32 to 110ยบ F
