Fluidwell - Model F070 -Field Mount - Level Indicator with Very Large Digits

SHARE

The F070 is a straight forward level indicator with large 26mm (1") high digits. It can be set to display the level as a quantity, height or percentage. The measuring unit to be displayed is simply selected through an alphanumeric configuration menu. No adhesive labels have to be put on the outside of the enclosure: a weather proof and user-friendly solution! The configuration of the Span, off-set and number of decimals is done through software functions, without any sensitive DIP-switches or trimmers.

Most popular related searches
level indicator
level monitoring
hazardous area
atmospheric temperature
snow temperature
  • Robust IP66, IP67 (NEMA Type4X) field enclosure. It is so rugged, you can even stand on it!
  • Intrinsically Safe available - ATEX, IECEx, FM and CSA approval for gas and dust applications.
  • Programming can be done by your own crew, with the sensible menu-driven structure, saving cost and irritation. Know one, know them all!
  • Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.
  • Displays level and height or percentage filled.
  • Very large 26mm (1") high digits for level.
  • Selectable on-screen engineering units for level: ml, L, m³, GAL, USGAL, kg, lb, bbl or no unit.
  • Selectable on-screen engineering units for height: mm, cm, m, mtr, inch, ft, mmwk, mmwc, cmwk, cmwc, mwk, mwc, inwc, ftwc, mBar, Bar, PSI or no unit.
  • Number of digits for level: 5½.
  • Piegraph indication: ten segments.
  • LED backlight with adjustable intensity.
  • Auto backup of settings in EEPROM memory.
  • Easy configuration with clear alphanumerical display.
  • Ambient temperature: -40°C to +80°C (-40°F to 176°F).
  • Various accessories are available for this product.
  • The F-Series is so rugged, even a truck can stand on it!
  • The F-Series is your first and best choice for field mount indicators in safe and hazardous area applications. Especially in harsh weather conditions like rain, snow, salty atmospheres and temperatures between -40°C up to +80°C (-40°F up to 176°F).
  • Applications where a basic level measurement display is required without level monitoring, linearization or signal re-transmission.
    Alternative advanced models: F073, F077, F170, F173 or the D-Series DIN panel mount indicators.

Power Supply

  • Long life Lithium battery.
  • 4 – 20mA, input Loop-powered.
  • 8 – 24V AC/DC.
  • 115 – 230V AC.
  • Basic: 8 - 30V DC.

Sensor Supply

  • 8.2, 12, 24V DC.
