BIOdek - Fills with Tubular Design

BIOdek - Fills with Tubular Design

BIOdek Fills with tubular design are used for biological water treatment and nitrification by contact aeration and for the separation of oil, fat and hydrocarbons. The fill consists of uniform parallel pipes (Tubes) with hexagonal shape. This design makes the BIOdek FAP specifically resistant to blockage and easy to clean.

Most popular related searches

biological water treatment

biofilm carrier media

Great process characteristics due to high contact surface and channel shape
Easy cleaning based on tubular channels
High resistance to blockage achieved by open hexagonal channel shape
Long service life provided by reinforced edges and chemical, bacterial and UV resistance of PP
Self-supporting structure - high bearing capacity achieved by sheet thickness and reliable welding

Material : PP
Void ratio (%) : >97 %
Length max (mm) : 2300
Width max (mm) : 300
Standard height (mm) : 305 or 610
Continuous operation temperature (°C) : 70
Max. operation temperature (short term) (°C) : -10 up to 80

BIOdek - Fills with Tubular Design

Advantages

Biodek Fap Tubular Design Fills

Bod5-Reduction

Nitrification
