Filox - Model KF 100 to KF 200 -Overhead Presses

suspension

The sliding suspension of the filter plates is maintenance and pendulum-free. It is not necessary to lock the individuals, as the static friction prevents the panels from being opened unintentionally.

Wash register Optional with wash register / filter cloth spreading device

After prolonged use of the filter cloths, they must be cleaned so that the original throughput can be achieved again. With the help of the automatic washing device, this work is done without any operator effort. The water pressure is a maximum of 100 bar.

Additional products:

• Discharge funnel
• Screw / twin screw conveyor
• Operating platforms / operating platforms
• Tilting containers and roll containers for cake dropping
• Feed pumps
• Special designs in container systems
• Mobile chamber filter presses
• Heating plate for filter cake drying
