FILTAWORX - Model FW050 - FW100 - Automatic Self-Cleaning Water Filters
From Filtration
FILTAWORX range of fully automatic self cleaning filters have been designed and built in Australia by an experienced team of engineers using the latest 3D CAD software. FILTAWORX® filters are one of the most technically innovative self-cleaning filters available, combining proven high performance, reliability and economy in a compact robust design.
Features
- Stainless steel filter body as standard.
- All parts are made of corrosion resistant materials.
- Fully automatic back flush operation.
- Available with hydraulic or electric controls.
- Large filtration area.
- Wide range of fine screen sizes, 50 to 800 microns.
- Standard sizes from DN50 to DN350 (2” – 14”).
- Pressure rating of PN10 as standard.
- Simple and quick installation.
- Full support and after sales service.
- Designed, built and tested in Australia
Advantages
Stainless Steel body for corrosion resistance in most environments.
Cleaning Mechanism:
The key feature to FILTAWORX® performance and reliability is the use of the escaping backflush water to rotate the internal cleaning mechanism inside the filter vessel. No external motor, mechanism or power is required, reducing the number of moving/wearing parts to a minimum.
Automatic Operation of the self cleaning backflush cycle is achieved when a pre-set pressure drop (40 - 50 kPa) across the filter is reached. 100% cleaning as every spot on the fine screen surface is cleaned with a high velocity, aggressive backflush flow.
No External Power is required (when using the hydraulic controlled filter). All functions are powered by the line pressure only. All controls required come complete with the filter.
Uninterrupted Flow during the backflush cycle.
More Screen Area than any other comparable filter available.
Positive Filtration using a precision 316 stainless steel mesh screen.
Wide Range of Filtration screen sizes available from 50 to 800 micron enabling correct selection for each application. Screens can easily be replaced on-site to alter the degree of filtration if required.
Compact and Simple Installation can be mounted in any position or orientation, with minimal space requirements.
High Reliability due to minimal moving parts, simple design and robust construction make FILTAWORX filters virtually maintenance free.
