Fining - Model FAS -60W Constant Voltage Waterproof LED Power Supply Adapter
The series are constant voltage mode output LED driver. T60W Constant Voltage Waterproof LED Power Supply is suitable for outdoor because of IP67 and great surge immunity. The user can select corresponding model according to market requirements.
Most popular related searches
Safety Approvals
CE, designed acording to UL/eTL/FCC standards
Mechanical Characteristics
Size:170x70x40MM Weight:0.55KG
- Input Condition: 100 to 240VAC 50/60Hz 1.5A Max
- Input Rated Voltage : 100 to 240VAC
- Input Voltage Range : 90 to 264VAC
- nput Rated Frequency : 50/60Hz
- Input Frequency Range : 47Hz to 63Hz
- Efficiency : 85% Min
- Rated Output Power: 60W
- Output Voltage & Current : 12VDC 5.0A
- Output Ripple And Noise : 1% Max
- Output Load Regulation: 5%
- Size:170x70x40MMWeight:0.55KG
- Protection : OCP OVP SCP OPP
- Operating Temperature and Humidity: 0 to 40℃
- Storage Temperature and Humidity: -10 to 85℃
- Relative Humidity: 20%-80%
- strip lights, landscape lights, bay lights, street lights, flood lights
