Firsa - Model 600LBS – FIG. 145 -Y Type Strainer
FromFirsa S.p.A.
Design according to ANSI B 16.34. Full range of body and screen materials. Bolted cover. Flanges according to ANSI B 16.5 from 2” to 24”. Flanges according to ANSI B 16.47 from 26”. Bw ends according to ANSI B 16.25. Face to face according to ANSI B 16.10.
Most popular related searches
- Standard screen perforation 1.5 mm round holes
- Other perforation or wire cloth are available on request
- Ratio between filtering area and piping section 2:1 minimum
- Testing according to
- API 598
- BS EN ISO 12266 PART 1
Special execution
See “ special features ”section
Material range
Valves are also available in Super Austenitic Duplex and Superduplex Steels , Nickel based Alloys , Titanium and Molibdenum 6
