Safe-Fire - Model EZ -Flame Detection System
Accurately detects burner flames at various stages of boiler startup and operation. Delivering superb flame discrimination via a highly sensitive optical sensor, high temperature resistance, and automatic self-checking, the EZ-Flame detector maximizes safety and minimizes maintenance requirements.
- Superb flame discrimination
- UV, IR and mixed UV/IR scanners
- Dual-channel amplifier
- Optional fiber optic cable assemblies
- Electronic self-checking routine
- Utilizes 3 flame characteristics for reliable detection
- User defined flame thresholds
- Simple and intuitive user interface
- 2 selectable program files per channel
- Explosion Proof models available
A truly advanced and user friendly flame detection system engineered for critical safetyfunctions in the Power Generation, Petrochemical, Metallurgy, and Pulp & Paper industries.Dual channel capabilities for IR, UV, or a combination UV and IR flame scanners provideflexibility to our customers. Each channel on the amplifier can store two user defined program files to distinguish unique flame characteristics. Safe-Fire’s EZ-Flame detection system performs accurate measurements on burner flamesat various stages of boiler startup and during operation to deliver reliable performance in oil, gas, and coal-fired burner applications
