McCrometer - Model SPI Mag - 282L -Flow Meter with ProComm Converter
The SPI Mag (Single Point Insertion) Electromagnetic Flow Meter is a hot tappable single point insertion flow meter for measuring forward flow. The sensor is available for one- inch or two-inch taps, depending upon line size and application.
The SPI Mag is a cost effective flow meter solution with a purchase price that is independent of line size making the cost to meter a sixty-inch line the same as a two-inch. The SPI Mag’s hot tap installation allows for uninterrupted service as it installs without
system shut-down, de-watering lines, cutting pipe or welding flanges. Installation costs are reduced by eliminating the need for heavy equipment or extensive manpower. The SPI can be easily re-located to various line sizes.
The compact insertion design fits in confined spaces and offers complete accessibility. The flow meter can be removed in pipes under pressure for easy inspection, cleaning, calibrating or verification. It is particularly cost- effective for retrofit applications replacing flow meters or in sites never metered before.
This cost effective flowmeter is available for line sizes from 2 to 96 inches. The flow sensor comes pre-calibrated from McCrometer’s NIST traceable Calibration Lab and requires no recalibration in the field. With no moving parts and a single-piece design, the SPI Mag’s sensor contains nothing to wear or break, and it is generally immune to clogging by sand, grit or other debris.
The SPI Mag is easily installed without interruption of the flow process. Sensor insertion hardware is utilized to insert the sensor through a ball valve or corporation stop in the flow conduit. Measurements are taken at the nearest pipe wall with negligible pressure drop in the pipe.
The SPI Mag allows profiling of the pipe inside diameter, further enhancing its measurement accuracy by allowing precise determination of mean velocities.
Both 1"and 2" sizes can be used for waste water and clean water.
Wastewater
- Effluent
- Waste Activated Sludge (WAS)
- Return Activated Sludge (RAS)
- Rclaim / Recycle
Clean Water
- Raw Water Intake
- Clear Wells
- Easy to relocate to various line sizes
- Ease of hot-tap installation
- Installs without service interruption
- Insertion design for total accessibility
- Price is independent of line size
- No moving parts
- Does not require recalibration in the field
- Pre-programmed
- Curve-fitting algorithm to improve accuracy
- 4-20mA (1000 ohm) analog output
- Eight line graphical display
- Six key touch programming
- Rugged enclosure meets IP67
