FTI - Flow Meters for Drum / Barrel Pumps
Designed to work with PF Series pump tubes, FTI’s line of flow meters allow customer’s to dispense precise volumes of fluids from drums, barrel, totes and other containers.
As liquid flows through the body of the flow meter, it rotates a paddlewheel sensor that has small magnets encapsulated in corrosion resistant plastic. As the paddlewheel rotates, the magnets pass by sensors creating a signal. A microprocessor converts these signals into flow and the results are shown on the liquid crystal display.
Available in corrosion resistant polypropylene or PVDF, FTI flow meters are designed to handle a wide variety of fluids including aggressive materials like acids and bases.
Engineered connection components are included with each meter to allow fast assembly to PFM, PFP and PFV drum pump tubes.
Factory calibrated to high +/- 1% accuracy and repeatability, some versions also allow the meter to be user calibrated for custom flow rates and fluid characteristics.
A variety of meters are available including batch control versions that stop the pump after a customer adjustable, preset volume is pumped.
Available models include FM1000, FM2000 and FM3000 series.
