Fluidesa - Model FP2 Duplex -Filter Cartridge Housings With Brass

• Guaranteed pressure
• Max working pressure (Pe): 10 BAR
• PED hydrostatic test pressure: >1,43 x Pe
• Internal test:
• Average breaking pressure: 35 BAR
• Cyclic test 0-10 bar: 100.000 cicli

NOTES

• Designed to hold cartridges 5”, 7”, 9”3/4, 20” (PP), D.70mm (Max);
• Cartridges not included;
• Accessories and spare parts p. 24.
