Guzzler - Model GF-0500D -Foot Button Pump
Foot Button Pump. Foot button pump with stainless steel return spring. Large inlet/outlet port size supports use in sewage/sanitation applications.
Most popular related searches
- Accommodates 1-1/4" - 2" hose
- Durable, lightweight Delrin plastic (weighs less than 2 lbs)
- 2.7 GPM
- Available with standard, lightweight or heavy duty stainless steel return spring
- Optional rubber boot/dust cover
- Max Pressure 7 psi / 0.40 bar
- Lift (dependent on spring selection)
- Head 15 ft / 4.6 m
- Capacity (dependent on spring selection) 2.7 gpm / 10.2 lpm
- Volume per stroke 0.18 qt / 0.17 l
- Max Service Temp 212° F / 100° C
- Rubber Boot: None
- Valves: Flapper (Buna-N)
- Diaphragm: Buna-N (Nitrile)
- Plunger-Button Assembly: Delrin Plastic
- Clamp Ring: Delrin Plastic
- Inlet Hose Connection: 1-1/2" Smooth
- Outlet Hose Connection: 1-1/2" Smooth
- Internal Spring: Standard Weight
- Pre-Pak Accessories: Not selected
- Body & Ports * Delrin / Gray
- Clamp Ring Delrin
- Valves * Flapper, Duckbill
- Diaphragm * Buna-N, Buna-N Double Sided, Neoprene, Viton, EPDM, Silicone Plunger/Button
- Assembly * Delrin
- Internal Spring * Lightweight (LW), Standard (STD), Heavy-Duty (HD), Extra Heavy Duty (XHD) (all stainless steel)
- Other Optional Rubber Boot (Dust Cover)
