Piedmont - Model BQ/BX-Style -FRP Bag Filters
The BQ-Style & BX-Style are Bag Filters made of fiberglass reinforced polyester (FRP) and they include unique components and design elements making it fit for multiple brands of universal cartridge elements. A cost-effective solution, this filter housing is a reliable protection for your BWRO and SWRO membrane systems. Piedmont’s cartridge filter housings are meant for new and existing water treatment plants.
Most popular related searches
bag filter
cartridge filter housing
water treatment plant
filter housing
water treatment plant engineering
SWRO membrane
cartridge filter
water treatment
filter bag
cartridge housing
- Flow rates: 21 – 1800 m3/h
- No. elements: 1-45
- Elements length: 17” & 32”
- Cartridge flow: Inside-Outside
- Housing layout: Vertical
- Features: Side inlet / Bottom outlet, Davit arm available
- Optional: Swing bolts
- Ideal: High flows and stand alone
- Design pressure: 6/10 bar
- Designed to ASME-X/EN 12121/ Ad Merkblatt / BS 4994 / AS 1210 code
- Design temperature s up to 90 C/ 194F
- Design pressure up to 10 bar / 150 psi
- Horizontal and vertical configuration available
- Internal lining of vynil ester Derakane 411, FDA/NSF compliant
- Davit arm and swing bolts available
- Coupling or flanged connection available
