Tanco - Model PLT-101 A -Fully Automatic Vertical Autoclave
Autoclave Vertical are most ideal for critical applications requiring assured and reliable total destruction of all living micro- organisms.Vertical autoclaveis low cost options for general sterilization ideal tool for Laboratories, Hospitals, Nursing Homes, R&D labs etc, Pharmaceutical, Food &Beverage Industries and Institutions
Most popular related searches
vertical autoclave
water level alarm
water level monitoring
programmable logic controller
automatic autoclave
autoclave
autoclave sterilizer
autoclaving sterilization
autoclave sterilization
air sterilizer
SALIENT FEATURES & CONSTRUCTION of Fully automatic Vertical Autoclave
- Inner & Outer Chamber, constructed from S. S. 304 Grade
- Bucket / Basket Made of Stainless Steel
- Water Level Indicator
- Lid Closing by Radial Locking System
- Sealing of Lid by Neoprene Rubber Gasket
- Lid is fitted with Pressure Gauge, Spring Loaded Safety Valve.
- Operating range from 15psi to 20psi pressure
- Sterilizing Temperature up to 1340C
- Tested up to 2.5 times of required Pressure
- Fully automatic models requiring no human intervention till a full sterilization cycle is over.
- Fitted with a (Programmable Logic Controller) LCD Display with respect to time and temperature.
- Enabling user automatic purging of stale air.
- Sterilizing hold time system for sterilizing period and cycle end.
- Automatic exhaust of pressure.
- Audio alarm/ buzzer is raised at the end of the cycle on.
- Voltage: 220 Volts AC (50 Hz)
All the instruments can be designed with PLC Based Control Systems (as per customer requirement) with Touch Screen Display / Controller data storage in Pen Drive with Direct Thermal / Dot matrix Printer. All the instruments can be designed with digital control systems (pid based LCD Display 16 x 2) with optional RS-485 communication ports, cables, window based software with inbuilt data recording.
CONTROL PANEL AND SWITCHGEARS
- µProcessor based Controller with time and temperature settable by user.
- (Pt-100) sensor, for precise i monitoring.
- Low water level alarm and cut off for safety of heater.
- End of cycle buzzer.
