ABBA - Model Albamat 900 V5 Z1 -Fully Automatic Vertical Channel Baling Presses System

• 90 t pressing force
• 1 main press cylinder
• large feed opening
• high bale weights
• Powerful and robust

• Ground slide and piston valve for covering the needle opening (prevents contamination of the binding unit with plastic or other small particles, etc.)
• Channel adjustment - 3 sides, hydraulic-automatic, 4 working cylinder
• 4 retaining clamps to retain expanding material in the press channel
• Photocell control in the filling chute
• Continuous feeding by conveyor belt etc.
• Fast cycle times
• Additional photocell for overfilling
• Pivoting tying unit for transport and service
• Simple and safe operation via 5.7" touch panel and push button function
• 10 programs for different materials (paper, foil, plastic, user recipes etc.)
• Operator side freely selectable
• Hopper as required

TYP: 900 V5 Z1

• Pressing force: [kN/t]: 900/90
• Specific pressing force: [N/cm²]: 76
• Motor: [kW]: 75 | 110
• Throughput weight cardboard 35 kg/m³ (B19): ca. [t/h]: 9,0 | 15,0
• Volume-idle running: [m³/h]: 679 | 825
• Volume-under working conditions B19: [m³/h]: 489 | 674
• Cycle time: [sec]: 16 | 13
• Feed opening: BxL: [mm]: 1.140 x 1.700
• Weight: approx. [kg]: 18.000
• Tying system: Vertical, 5-fold, automatic
• Bale size W x H x L: [mm]: 1.080 x 1.110 x 1200
• Bale weight– cardboard B19 (depending on type of material): [kg]: up to 800 kg
